Koeffizient-Thermistor Temp-Maß des Epoxidthermistor-3470 negatives
Produktdetails:
| Herkunftsort: | China |
| Markenname: | Hefei Minsing |
| Zertifizierung: | REACH ,ROHS |
| Modellnummer: | MF5A-3 |
Zahlung und Versand AGB:
| Min Bestellmenge: | 500pcs |
|---|---|
| Preis: | negotiable |
| Verpackung Informationen: | Masse |
| Lieferzeit: | 2-10 Arbeitstage |
| Zahlungsbedingungen: | T/T |
| Versorgungsmaterial-Fähigkeit: | 50 Million Stücke pro Jahr |
|
Detailinformationen |
|||
| Name: | Epoxidthermistor 3470 | Anschlussleitung: | Cp/Sn (Φ0.3, Φ0.4, Φ0.5 optional) |
|---|---|---|---|
| Hauptgröße: | Φ1.5-Φ3.5mm | Seillänge: | 10-36mm |
| R25℃: | 0.5KΩ-2000KΩ | Anderer Name: | Negativer Koeffizient-Thermistor |
| R Toleranz-: | 0,5%, 1%, 2%, 3%, 5% | B-Toleranz: | 0,5%, 1%, 2%, 3%, 5% |
| Hervorheben: | Epoxidthermistor 3470,Negativer Thermistor des Koeffizient-3470,Temp-Maß-Epoxidthermistor |
||
Produkt-Beschreibung
3470 Epoxy Thermistor Negative Coefficient Thermistor Temp Measurement
3470 Epoxy Thermistor Features
1: small size,strong power,strong capability of surge current protection
2: fast response to surge corrent
3: big material constant(B value),small remain resistance
4: longevity of service,high reliability
Specification Explain:
SJ MF 5A-3 -3470 -502 F
① ② ③ ④ ⑤ ⑥
① Minsing Co.,Ltd
② NTC thermistor
③ Epoxy coating type 5A-3 series
④ B value(B 25/50℃) Example: 3470:B 25/50℃: 3470
⑤ Standard resistance value at 25℃(R25℃):
Example:502:R25℃ 5KΩ,103:R25℃ 10KΩ ,104:R25℃ 100KΩ
⑥ R25℃ interchangeability precision:
F(±1%); G(±2%); H(±3%); J(±5%); K(±10%)
Specification of 3470 Epoxy Thermistor :
| Specification | R25℃ (KΩ) | B25/50℃ (K) | Disspation constant | Thermal time constant | Operating temp. range |
| SJMF5A-□-347/395/385-202□ | 2 | 3470/3950/3850 |
ln still air ≥ 2.1mW/℃ |
ln still air ≤ 12s |
-40～+150℃ |
| SJMF5A-□-327/347/395-502□ | 5 | 3270/3470/3950 | |||
| SJMF5A-□-338/347/390-103□ | 10 | 3380/3470/3900 | |||
| SJMF5A-□-395/420/405-473□ | 47 | 3950/4200/4050 | |||
| SJMF5A-□-395/420/405-503□ | 50 | 3950/4200/4050 | |||
| SJMF5A-□-395/348-152□ | 1.5 | 3950/3480 | |||
| SJMF5A-□-397/418-104□ | 100 | 3970/4180 | |||
| SJMF5A-□-453-105□ | 1000 | 4530 |
□ R25℃ interchangeability precision , B value precision ±1% ±2% ±3% ±5%
B value among 3000-4500K,and R25℃ among 0.5KΩ-2000KΩ. MF5A can be custom designed.
